Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
9.78 m
Specs
Main
Name | Value |
---|---|
Maker | X-Yachts |
Maker website | https://www.x-yachts.com |
Model | Xp 33 |
First built hull | 2012 |
Price | 117,000 € |
Boat type | Sail |
Category | Racer Boats |
Hull type | Monohull |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Top speed | 11.59 kmh |
Length overall | 9.78 m |
Length at waterline | 8.56 m |
Beam overall | 3.23 m |
Draft maximum | 1.89 m |
Displacement | 4,300.05 kg |
Ballast weight | 1,700.06 kg |
Ballast type | Cast iron fin with lead bulb |
Helm | 1 tiller |
Rudder | 1 spade rudder |
Cockpit | Open aft cockpit |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | X-Yachts Design Group |
Website | http://www.x-yachts.com/ |
Rig & Sails
Name | Value |
---|---|
Spars | Mast and boom in Aluminum (carbon fiber as an option) |
Standing rigging | Single-strand (ROD) |
Number of spreaders | 2 |
Spreaders angle | Swept-back |
Upwind sail area | 62.99 sq.m |
Downwind sail area | 126.81 sq.m |
Mainsail A | 364.00 |
Spinnaker A | 1001.00 |
Engine
Name | Value |
---|---|
Engine A | |
Power | 21 HP |
Type | Inboard engine ; Diesel |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.06 |
Upwind SA to Displacement | 24.23 |
Downwind SA to Displacement | 48.77 |
Hull Displacement Speed | 0.06 |
Displacement to Length (D/L) | 7.1 |
Ballast to Displacement (B/D) | 0.4 |
Capsize Screening Formula (CSF) | 2.01 |
