2011 X-Yachts Xp 38 Deep draft

1404

0

2011 X-Yachts Xp 38 Deep draft
Preview

Boat Overview

  • Type
    sail
  • Maker
    X-Yachts
  • Hull type
    monohull
  • Hull Material
    fiberglass
  • Category
    -
  • Boat length (LOA)
    11.58 m

Discover the Gold

Hide ads, help pay for servers & development and unlock Gold only features like, sharing, advanced dashboard, extra storage space & more!

Try Gold for Free

Specs

Main
NameValue
MakerX-Yachts
Maker website-
ModelXp 38 Deep draft
First built hull2011
Last built hull-
VersionDeep draft
Price246000 EUR
Boat typesail
Category-
Hull typemonohull
Hull materialfiberglass
Cabins-
Births-
Heads-
General
NameValue
Top speed12.57 kmh
Cruising speed-
Mast height-
Length overall11.58 m
Length at waterline10.36 m
Beam overall3.69 m
Beam center-line-
Beam hull-
Headroom-
Bridgedeck clearance-
Nominal bridgedeck clearance-
Draft maximum2.17 m
Draft minimum-
Displacement6773.70 kg
Tonnage Gross-
Tonnage Net-
Ballast weight2759.64 kg
Ballast typeCast iron fin with lead bulb
Helm2 wheels
Rudder1 spade rudder
Hull appendages
Hull appendages A-
CockpitOpen aft cockpit
Unsinkable-
Trailerable-
CE classification
CE classification A-
CE classification B-
CE classification C-
CE classification D-
Designer
NameValue
Naval architect
Name/StudioX-Yachts Design Group
Websitehttp://www.x-yachts.com/
Exterior designer
Name/Studio-
Website-
Interior designer
Name/Studio-
Website-
Rig & Sails
NameValue
Riggingsloop
Rotating spars-
Mast-
SparsMast and boom in Aluminum (carbon fiber as an option)
Standing riggingSingle-strand (ROD)
Number of spreaders2
Spreaders angleSwept-back
Upwind sail area85.56 sq.m
Downwind sail area178.47 sq.m
Mainsail
Mainsail A522.00
Headsail
Headsail A-
Spinnaker
Spinnaker A1399.00
Engine
NameValue
Engine A
Maker-
Website-
Model-
TypeInboard engine ; Diesel
Drive-
Fuel-
Power29
Power Typehp
Engine B
Maker-
Website-
Model-
Type-
Drive-
Fuel-
Power-
Power Typehp
Storage
NameValue
Fuel tank
Fuel tank A149.89 liter
Water tank
Water tank A260.03 liter
Holding tank
Holding tank A-
Water heater
Water heater A-

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 13.78
Upwind SA to Displacement24.31
Downwind SA to Displacement50.7
Hull Displacement Speed 7.81
Displacement to Length (D/L) 169.65
Ballast to Displacement (B/D) 40.74
Capsize Screening Formula (CSF) 1.97
Stability Speed-
Kelsall Stability Index (KSI)-
