Specs

Main
MakerX-Yachts
Maker websitehttps://www.x-yachts.com
ModelXp 38 Standard
First built hull2011
VersionStandard
Boat typeSail
CategoryRacer Boats
Hull typeMonohull
Hull materialFiberglass
General
Top speed12.57 kmh
Length overall11.58 m
Length at waterline10.36 m
Beam overall3.69 m
Draft maximum1.86 m
Displacement6,775 kg
Ballast weight2,760 kg
Ballast typeCast iron fin with lead bulb
Helm2 wheels
Rudder1 spade rudder
CockpitOpen aft cockpit
Designer
Naval architect
Name/StudioX-Yachts Design Group
Websitehttp://www.x-yachts.com/
Rig & Sails
SparsMast and boom in Aluminum (carbon fiber as an option)
Standing riggingSingle-strand (ROD)
Number of spreaders2
Spreaders angleSwept-back
Upwind sail area85.56 sq.m
Downwind sail area178.47 sq.m
Engine
Engine B
Power29 HP
TypeInboard
Storage
Fuel tank A149.9 liter
Water tank A260.06 liter

Performance & Ratios

Detail
Sail Area to Displacement (SA/D) 24.3
Upwind SA to Displacement24.3
Downwind SA to Displacement50.68
Hull Displacement Speed 7.81
Displacement to Length (D/L) 169.65
Ballast to Displacement (B/D) 0.41
Capsize Screening Formula (CSF) 1.97
