Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
10.82 m
Specs
Main
| Maker | Yachting France |
| Model | Jouët 1080 Deep draft |
| First built hull | 1983 |
| Version | Deep draft |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 12.01 kmh |
| Length overall | 10.82 m |
| Length at waterline | 9.45 m |
| Beam overall | 3.69 m |
| Beam hull | 2.01 m |
| Draft maximum | 1.98 m |
| Displacement | 5,600.05 kg |
| Ballast weight | 2,500.2 kg |
| Ballast type | Cast iron |
| Helm | 1 tiller |
| Rudder | 1 semi-spade rudder |
| Cockpit | Closed aft cockpit |
Designer
Rig & Sails
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire |
| Number of spreaders | 2 |
| Spreaders angle | 0 ° |
| Upwind sail area | 73.39 sq.m |
| Downwind sail area | 143.26 sq.m |
Engine
| Engine A | |
| Power | 35 HP |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.06 |
| Upwind SA to Displacement | 23.67 |
| Downwind SA to Displacement | 46.2 |
| Hull Displacement Speed | 0.06 |
| Displacement to Length (D/L) | 7.46 |
| Ballast to Displacement (B/D) | 0.45 |
| Capsize Screening Formula (CSF) | 2.1 |
