Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
7.22 m
Specs
Main
Name | Value |
---|---|
Maker | Yachting France |
Model | Jouët 24 |
First built hull | 1977 |
Boat type | Sail |
Category | Cruiser Boats |
Hull type | Monohull |
Hull material | Composite_Material |
General
Name | Value |
---|---|
Top speed | 9.88 kmh |
Mast height | 11.13 m |
Length overall | 7.22 m |
Length at waterline | 6.4 m |
Beam overall | 2.47 m |
Headroom | 1.77 m |
Draft maximum | 1.25 m |
Displacement | 1,749.96 kg |
Ballast weight | 820.09 kg |
Ballast type | Cast iron |
Helm | 1 tiller |
Rudder | 1 transom hung rudder |
Cockpit | Closed aft cockpit |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Daniel Tortarolo |
Rig & Sails
Name | Value |
---|---|
Mast | 36.5 |
Spars | Mast and boom in Aluminum |
Standing rigging | 1x19 strand wire continuous |
Number of spreaders | 1 |
Spreaders angle | Swept-back |
Upwind sail area | 30.66 sq.m |
Downwind sail area | 22.48 sq.m |
Mainsail A | 135.00 |
Spinnaker A | 108.00 |
Spinnaker A | 118.00 |
Engine
Name | Value |
---|---|
Engine A | |
Type | Outboard or inboard engine |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.02 |
Upwind SA to Displacement | 21.47 |
Downwind SA to Displacement | 15.75 |
Hull Displacement Speed | 0.02 |
Displacement to Length (D/L) | 6.14 |
Ballast to Displacement (B/D) | 0.47 |
Capsize Screening Formula (CSF) | 2.07 |
