1975 Jeanneau Aquila

No gallery images

1975 Jeanneau Aquila
Preview

Boat Overview

Boat Description

Jeanneau, the master shipbuilders from France, continue in their tradition of maritime excellence with the Aquilla. This vessel's hull, built with a profound understanding of hydrodynamics, boasts both stability and agility, an unusual pairing that ensures smooth sailing with tumultuous waters. It's an exemplar of structure and form, a fine instance of nautical craftsmanship where every beam, keel and bulkhead plays a crucial role.

Embrace the Aquilla, embrace the promise of unforgettable marine adventures. Set sail towards the horizon.

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Gold for Free

Specs

Main
NameValue
MakerJeanneau
Maker websitehttps://www.jeanneau.fr
ModelAquila
First built hull1975
VersionShoal draft
Price15,953 $
Boat typeSail
CategoryCruiser/Racer BoatsDaysailer Boats
Hull typeMonohull
Hull materialMonohull
Cabins1
Births4
Heads1
General
NameValue
Top speed10.41 kmh
Mast height11.31 m
Length overall8.72 m
Length at waterline7.13 m
Beam overall2.77 m
Headroom1.83 m
Draft maximum1.34 m
Displacement3,499.92 kg
Ballast weight949.82 kg
Ballast typeCast iron
Helm1 tiller
Rudder1 semi-spade rudder
CockpitClosed aft cockpit
Designer
NameValue
Naval architect
Name/StudioPhilippe Harlé
Rig & Sails
NameValue
Mast37.1
SparsMast and boom in Aluminum
Standing rigging1x19 strand wire continuous
Number of spreaders1
Spreaders angle0 °
Upwind sail area40.41 sq.m
Downwind sail area71.26 sq.m
Mainsail A150
Headsail A285
Headsail B244
Headsail C136
Headsail D51
Spinnaker A618
Engine
NameValue
Engine A
FuelDiesel
Power12 HP
TypeInboard
Storage
NameValue
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 6.15
Upwind SA to Displacement17.83
Downwind SA to Displacement31.44
Hull Displacement Speed 6.48
Displacement to Length (D/L) 268.84
Ballast to Displacement (B/D) 27.14
Capsize Screening Formula (CSF) 1.84
