Boat Overview

Boat Description

Philippe Harlé, when he put his pen to the drawing-board came up with a hull design which is rare in its efficiency. Finely raked bow lines running all the way aft to a beam stern section; afloat, the balance of the Fantasia 27 is what makes her stand out. The contribution of the teak woodwork and trims reinforces the light and amazingly commodious character of the Fantasia 27 below decks. The set choice of aft cabin, quite separate with its double berth in symmetry with the head, leaves free the appointment midship and forward of the L-shaped saloon and double-berth forward, with 1,80 m (5'11') headroom throughout! Large ports and hatches (round port ins aft cabin forward screen of roof) bathe the daily life of those aboard in light and good cheer.

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Pro for Free

Specs

Main
NameValue
MakerJeanneau
Maker websitehttps://www.jeanneau.fr
ModelFantasia 27
First built hull1982
Last built hull1992
Price12,229 $
Boat typeSail
CategoryCruiser BoatsDaysailer Boats
Hull typeMonohull
Hull materialMonohull
Cabins2
Births5
Heads1
General
NameValue
Top speed10.01 kmh
Length overall8.29 m
Length at waterline6.58 m
Beam overall2.9 m
Headroom1.86 m
Draft maximum1.25 m
Displacement2,399.96 kg
Ballast weight749.79 kg
Ballast typeCast iron
Helm1 tiller
Rudder1 transom hung rudder
CockpitClosed aft cockpit
Designer
NameValue
Naval architect
Name/StudioPhilippe Harlé
Rig & Sails
NameValue
SparsMast and boom in Aluminum
Standing rigging1x19 strand wire continuous
Number of spreaders1
Upwind sail area35.21 sq.m
Downwind sail area60.94 sq.m
Mainsail A138
Headsail A241
Headsail B203
Headsail C115
Headsail D48
Spinnaker A518
Engine
NameValue
Engine A
FuelDiesel
TypeInboard
Storage
NameValue
Simple Empty
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 0.04
Upwind SA to Displacement19.98
Downwind SA to Displacement34.58
Hull Displacement Speed 0.04
Displacement to Length (D/L) 6.23
Ballast to Displacement (B/D) 0.31
Capsize Screening Formula (CSF) 2.18
