Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
10.58 m
Specs
Main
| Name | Value |
|---|---|
| Maker | Jeanneau |
| Maker website | https://www.jeanneau.fr |
| Model | Melody |
| First built hull | 1976 |
| Version | Deep draft |
| Price | 8,000 € |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
| Cabins | 2 |
| Births | 6 |
| Heads | 1 |
General
| Name | Value |
|---|---|
| Top speed | 11.52 kmh |
| Mast height | 15.88 m |
| Length overall | 10.58 m |
| Length at waterline | 8.72 m |
| Beam overall | 3.38 m |
| Headroom | 1.98 m |
| Draft maximum | 1.89 m |
| Displacement | 6,000.11 kg |
| Ballast weight | 2,899.81 kg |
| Ballast type | Cast iron |
| Helm | 1 tiller |
| Rudder | 1 semi-spade rudder |
| Cockpit | Closed aft cockpit |
Designer
| Name | Value |
|---|---|
| Naval architect | |
| Name/Studio | Bureau Mauric |
| Website | http://www.mauric.com |
Rig & Sails
| Name | Value |
|---|---|
| Mast | 52.1 |
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire continuous |
| Number of spreaders | 1 |
| Spreaders angle | 0 ° |
| Upwind sail area | 74.97 sq.m |
| Downwind sail area | 124.95 sq.m |
| Mainsail A | 269 |
| Headsail A | 538 |
| Headsail B | 355 |
| Headsail C | 226 |
| Headsail D | 97 |
| Spinnaker A | 1076 |
Engine
| Name | Value |
|---|---|
| Engine A | |
| Fuel | Diesel |
| Power | 27 HP |
| Type | Inboard |
Storage
| Name | Value |
|---|---|
No data | |
Performance & Ratios
Detail
| Name | Value |
|---|---|
| Sail Area to Displacement (SA/D) | 0.05 |
| Upwind SA to Displacement | 23.09 |
| Downwind SA to Displacement | 38.49 |
| Hull Displacement Speed | 0.05 |
| Displacement to Length (D/L) | 7.17 |
| Ballast to Displacement (B/D) | 0.48 |
| Capsize Screening Formula (CSF) | 1.88 |
