Boat Overview

Boat Description

The Sangria is a recreational keel boat, built predominantly of single skin fiberglass polyester, with wooden trim. It has a masthead sloop rig, with a deck-stepped mast, one set of spreaders and aluminum spars with stainless steel wire rigging. The hull has a raked stem, a plumb transom, a skeg-mounted rudder controlled by a tiller and a fixed fin keel or deep draft keel in the GTE mode.

The design has sleeping accommodation for four people, with a double "V"-berth in the bow cabin and two straight settee berths in the main cabin. The galley is located on the starboard side just forward of the companionway ladder. The galley is equipped with a two-burner stove, ice box and a small sink. The head is located just aft of the bow cabin on the port side.

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Pro for Free

Specs

Main
NameValue
MakerJeanneau
Maker websitehttps://www.jeanneau.fr
ModelSangria
First built hull1969
Last built hull1982
Price10,000 €
Boat typeSail
CategoryCruiser BoatsSports Cruiser Boats
Hull typeMonohull
Hull materialMonohull
General
NameValue
Top speed9.41 kmh
Mast height10.55 m
Length overall7.62 m
Length at waterline5.79 m
Beam overall2.47 m
Headroom1.74 m
Draft maximum1.25 m
Displacement2,039.8 kg
Ballast weight790.16 kg
Ballast typeCast iron
Helm1 tiller
Rudder1 semi-spade rudder
CockpitClosed aft cockpit
Designer
NameValue
Naval architect
Name/StudioPhilippe Harlé
Rig & Sails
NameValue
Mast34.6
SparsMast and boom in Aluminum
Standing rigging1x19 strand wire continuous
Number of spreaders1
Spreaders angle0 °
Upwind sail area31.49 sq.m
Downwind sail area52.95 sq.m
Mainsail A135
Headsail A205
Headsail B161
Headsail C108
Headsail D54
Spinnaker A436
Engine
NameValue
Engine A
FuelDiesel
Power8 HP
TypeInboard
Storage
NameValue
Simple Empty
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 0.04
Upwind SA to Displacement19.91
Downwind SA to Displacement33.48
Hull Displacement Speed 0.04
Displacement to Length (D/L) 5.84
Ballast to Displacement (B/D) 0.39
Capsize Screening Formula (CSF) 1.97
