1990 Jeanneau Sun Fast 41

1666

Report error

1990 Jeanneau Sun Fast 41

No gallery images

1990 Jeanneau Sun Fast 41

Boat Overview

Boat Description

When a renowned shipyard appeals to the most successful designer in competition, Doug Peterson, an undisputed master of contemporary architecture, has to live up to his expectations.

Overview

Specs
Main
General
Designer
Rig & Sails
Engine
Storage
Performance & Ratios
Detail

Specs

Main
MakerJeanneau
Maker websitehttps://www.jeanneau.fr
ModelSun Fast 41
First built hull1990
Last built hull1994
Price50,000 €
Boat typeSail
CategoryCruiser Boats
Hull typeMonohull
Hull materialFiberglass
Cabins2
Births4
Heads1
General
Top speed12.34 kmh
Length overall12.5 m
Length at waterline10 m
Beam overall3.69 m
Beam hull1.98 m
Draft maximum1.98 m
Displacement7,799.97 kg
Ballast weight3,119.81 kg
Ballast typeCast iron
Helm1 helm wheel
Rudder1 spade rudder
CockpitClosed aft cockpit
Designer
Naval architect
Name/StudioDouglas Peterson
Rig & Sails
SparsMast and boom in Aluminum
Standing rigging1x19 strand wire
Number of spreaders2
Spreaders angle0 °
Upwind sail area88.07 sq.m
Downwind sail area149.67 sq.m
Engine
Engine A
FuelDiesel
Power55 HP
Typeinboard
Storage

Performance & Ratios

Detail
Sail Area to Displacement (SA/D) 0.05
Upwind SA to Displacement22.78
Downwind SA to Displacement38.7
Hull Displacement Speed 0.05
Displacement to Length (D/L) 7.67
Ballast to Displacement (B/D) 0.4
Capsize Screening Formula (CSF) 1.88
