Boat Overview

Boat Description

Integrating all the latest improvements and key innovations of the Sun Odyssey line, this 13-metre sailboat is fast and easy to manoeuvre. The Sun Odyssey 419 (42’) is available in two- or three-cabin configurations. Designed by Philippe Briand, she offers a refined style, with elegant lines and a bright interior.




Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Pro for Free

Specs

Main
NameValue
MakerJeanneau
Maker websitehttps://www.jeanneau.fr
ModelSun Odyssey 419
First built hull2015
Price161,300 €
Boat typeSail
CategoryCruiser BoatsDaysailer Boats
Hull typeMonohull
Hull materialMonohull
Cabins3
Births8
Heads2
General
NameValue
Top speed12.96 kmh
Mast height18.44 m
Length overall12.53 m
Length at waterline12.01 m
Beam overall3.99 m
Headroom1.98 m
Draft maximum1.86 m
Displacement7,859.84 kg
Ballast weight2,259.8 kg
Ballast typeCast iron
Helm2 wheels
Rudder1 spade rudder
CockpitClosing aft cockpit with opening system
CE classification A8
CE classification B10
CE classification C12
Designer
NameValue
Simple Empty
No data
Rig & Sails
NameValue
Mast60.5
SparsMast and boom in Aluminum
Standing rigging1x19 strand wire
Number of spreaders2
Spreaders angleSwept-back
Upwind sail area89.56 sq.m
Downwind sail area161.47 sq.m
Mainsail A468
Headsail A496
Headsail B350
Headsail C304
Spinnaker A1270
Spinnaker A1173
Engine
NameValue
Engine A
FuelDiesel
MakerYanmar
Model40 CV
Power40 HP
TypeInboard
Storage
NameValue
Simple Empty
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 0.05
Upwind SA to Displacement23.04
Downwind SA to Displacement41.54
Hull Displacement Speed 0.05
Displacement to Length (D/L) 8.41
Ballast to Displacement (B/D) 0.29
Capsize Screening Formula (CSF) 2.03
