Boat Overview

Boat Description

The Sun Odyssey 490 benefits from all the advantages of the line:  easy flow of movement on board, comfortable cruising, and clever layouts in short, the ability to combine seaworthy qualities and a high quality of life on board.

Flagship of the Sun Odyssey line, this 49-foot sailboat feels remarkably spacious through out. The forward cabin is a true parental suite, featuring a berth of 1.60 by 2 metres, copious storage, a hanging locker, centrally located built-in bookshelves with an integrated television, and private access to a comfortable bathroom with separate shower, sink, and heads. All is bathed in light, well-ventilated, and benefits from sound insulation. The spacious saloon, the fully equipped galley, and options for one or two additional cabins complete the offering, for a truly harmonious life on board.

Well-protected and secure while cruising, the cockpit transforms into a living area for pure relaxation when at anchor, with a sundeck, a wide swim platform, and additional options to make sunny stops more enjoyable, including a cooler and bottle holder. Aboard the Sun Odyssey 490, it's la dolce vita. But this sailboat is also, or especially, a proud cruiser designed for longer crossings: stable, high-performance, and safe. It is responsive at the helm and easy to handle, despite its size and whether cruising or at port, notably with a bow thruster, located aft.

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Gold for Free

Specs

Main
NameValue
MakerJeanneau
Maker websitehttps://www.jeanneau.fr
ModelSun Odyssey 490
First built hull2022
VersionDeep draft
Price410,168 €
Boat typeSail
CategoryCruiser BoatsDaysailer Boats
Hull typeMonohull
Hull materialMonohull
Cabins3
Births8
Heads2
General
NameValue
Top speed14.21 kmh
Mast height19.93 m
Length overall14.45 m
Length at waterline13.26 m
Beam overall4.51 m
Headroom2.01 m
Draft maximum2.26 m
Displacement11,289.9 kg
Ballast weight2,869.88 kg
Ballast typeCast iron
Helm2 wheels
Rudder2 spade rudders
CockpitClosing aft cockpit with opening system
CE classification A9
CE classification B10
CE classification C14
Designer
NameValue
Naval architect
Name/StudioPhilippe Briand
Websitehttp://www.philippebriand.com
Rig & Sails
NameValue
Mast65.4
SparsMast and boom in Aluminum
Standing rigging1x19 strand wire discontinuous
Number of spreaders2
Spreaders angleSwept-back
Upwind sail area111.39 sq.m
Downwind sail area150.32 sq.m
Mainsail A622
Headsail A577
Spinnaker A996
Engine
NameValue
Engine A
FuelDiesel
MakerYanmar
Model80 CV
Power80 HP
TypeInboard
Storage
NameValue
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 11.68
Upwind SA to Displacement22.51
Downwind SA to Displacement30.38
Hull Displacement Speed 8.84
Displacement to Length (D/L) 134.99
Ballast to Displacement (B/D) 25.42
Capsize Screening Formula (CSF) 2.03
