1985 Jeanneau Tonic 23

1603

Report error

1985 Jeanneau Tonic 23

No gallery images

1985 Jeanneau Tonic 23
Preview

Boat Overview

Boat Description

Ever ready for a quick get-away on her trailer: the Tonic 23 is adapted to the different styles of sailing which we so enjoy. In lifting or fixed keel versions, beaching is real play. Fast through the water, she is a truly easy and comfortable sailboat. This 23 à foot design from Philippe Harlés drawing board brings together for the first time: a six-water U-shaped saloon with 1,70 m headroom (5'7'); a genuine chart table, a galley fully fitted out with numerous storage lockers, an independent washroom, a roomy hanging locker, a double cabin aft and a large sails locker.

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Pro for Free

Specs

Main
NameValue
MakerJeanneau
Maker websitehttps://www.jeanneau.fr
ModelTonic 23
First built hull1985
Last built hull1992
Price12,500 €
Boat typeSail
CategoryCruiser BoatsDaysailer Boats
Hull typeMonohull
Hull materialMonohull
Cabins1
Births4
Heads1
General
NameValue
Top speed9.72 kmh
Mast height11.73 m
Length overall7.04 m
Length at waterline6.22 m
Beam overall2.5 m
Headroom1.55 m
Draft maximum1.16 m
Displacement1,299.99 kg
Ballast weight449.96 kg
Ballast typeCast iron
Helm1 tiller
Rudder1 transom hung rudder
CockpitClosed aft cockpit
Designer
NameValue
Naval architect
Name/StudioHarlé-Mortain
Rig & Sails
NameValue
Mast38.5
SparsMast and boom in Aluminum
Standing riggingContinuous
Number of spreaders1
Spreaders angleSwept-back
Upwind sail area29.36 sq.m
Downwind sail area48.4 sq.m
Mainsail A157
Headsail A159
Headsail B140
Headsail C86
Headsail D43
Spinnaker A364
Engine
NameValue
Engine A
Power10 HP
TypeOutboard
Storage
NameValue
Simple Empty
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 0.05
Upwind SA to Displacement19.74
Downwind SA to Displacement32.55
Hull Displacement Speed 0.05
Displacement to Length (D/L) 6.05
Ballast to Displacement (B/D) 0.35
Capsize Screening Formula (CSF) 2.31
