Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
15.42 m
Specs
Main
Name | Value |
---|---|
Maker | Jeanneau |
Maker website | https://www.jeanneau.fr |
Model | Yachts 51 Shoal draft |
First built hull | 2016 |
Version | Shoal draft |
Price | 282,000 € |
Boat type | Sail |
Category | Cruiser Boats |
Hull type | Monohull |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Top speed | 14.6 kmh |
Mast height | 21.95 m |
Length overall | 15.42 m |
Length at waterline | 14.97 m |
Beam overall | 4.72 m |
Draft maximum | 1.77 m |
Displacement | 14,850.15 kg |
Ballast weight | 4,750.02 kg |
Ballast type | Cast iron |
Helm | 2 wheels |
Rudder | 1 spade rudder |
Cockpit | Open aft cockpit |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Philippe Briand |
Website | http://www.philippebriand.com |
Rig & Sails
Name | Value |
---|---|
Mast | 72 |
Spars | Mast and boom in Aluminum |
Standing rigging | 1x19 strand wire discontinuous |
Number of spreaders | 2 |
Spreaders angle | Swept-back |
Upwind sail area | 118.82 sq.m |
Downwind sail area | 162.86 sq.m |
Mainsail A | 677.00 |
Mainsail B | 448.00 |
Mainsail C | 1076.00 |
Engine
Name | Value |
---|---|
Engine A | |
Power | 110 HP |
Type | Inboard engine ; Diesel |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.03 |
Upwind SA to Displacement | 20 |
Downwind SA to Displacement | 27.42 |
Hull Displacement Speed | 0.03 |
Displacement to Length (D/L) | 9.39 |
Ballast to Displacement (B/D) | 0.32 |
Capsize Screening Formula (CSF) | 1.94 |
