Boat Overview

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Pro for Free

Specs

Main
NameValue
MakerKirie
ModelElite 32 - Deep draft
First built hull1981
VersionDeep draft
Boat typeSail
CategoryCruiser/Racer Boats
Hull typeMonohull
Hull materialMonohull
General
NameValue
Top speed10.9 kmh
Mast height13.05 m
Length overall9.69 m
Length at waterline7.8 m
Beam overall3.26 m
Headroom1.86 m
Draft maximum1.77 m
Displacement4,250.16 kg
Ballast weight1,359.87 kg
Ballast typeCast iron
Helm1 tiller
Rudder1 semi-spade rudder
CockpitClosed aft cockpit
Designer
NameValue
Naval architect
Name/StudioPhilippe Harlé
Rig & Sails
NameValue
Mast42.8
SparsMast and boom in Aluminum
Standing rigging1x19 strand wire continuous
Number of spreaders1
Spreaders angle0 °
Upwind sail area52.03 sq.m
Downwind sail area91.51 sq.m
Mainsail A210.00
Spinnaker A775.00
Spinnaker A163.00
Spinnaker A70.00
Engine
NameValue
Engine A
Power18 HP
TypeInboard engine ; Diesel
Engine B
Storage
NameValue
Simple Empty
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 0.04
Upwind SA to Displacement20.17
Downwind SA to Displacement35.47
Hull Displacement Speed 0.04
Displacement to Length (D/L) 6.78
Ballast to Displacement (B/D) 0.32
Capsize Screening Formula (CSF) 2.03
