Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
9.97 m
Specs
Main
| Maker | Kirie |
| Model | Elite 324 - Shoal Draft |
| First built hull | 1986 |
| Version | Shoal Draft |
| Boat type | Sail |
| Category | Cruiser/Racer Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 10.91 kmh |
| Length overall | 9.97 m |
| Length at waterline | 7.83 m |
| Beam overall | 3.26 m |
| Beam hull | 1.89 m |
| Draft maximum | 1.34 m |
| Displacement | 3,899.98 kg |
| Ballast weight | 1,359.87 kg |
| Ballast type | Cast iron |
| Helm | 1 tiller (helm wheel in option) |
| Rudder | 1 spade rudder |
| Cockpit | Closed aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Philippe Harlé |
Rig & Sails
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire |
| Number of spreaders | 2 |
| Spreaders angle | 0 ° |
| Upwind sail area | 57.04 sq.m |
| Downwind sail area | 93.74 sq.m |
Engine
| Engine A | |
| Engine B | |
| Power | 18 HP |
| Type | inboard |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.05 |
| Upwind SA to Displacement | 23.42 |
| Downwind SA to Displacement | 38.48 |
| Hull Displacement Speed | 0.05 |
| Displacement to Length (D/L) | 6.79 |
| Ballast to Displacement (B/D) | 0.35 |
| Capsize Screening Formula (CSF) | 2.09 |
