Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
9.57 m
Specs
Main
| Maker | Kirie |
| Model | Elite 326 - Centerboard (Trunk) |
| First built hull | 1987 |
| Version | Centerboard (Trunk) |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 11.23 kmh |
| Mast height | 13.05 m |
| Length overall | 9.57 m |
| Length at waterline | 8.29 m |
| Beam overall | 3.38 m |
| Beam hull | 1.56 m |
| Draft maximum | 1.58 m |
| Displacement | 4,419.8 kg |
| Ballast weight | 1,460.11 kg |
| Ballast type | Cast iron interior ballast with glass-fiber/polyester centerboard |
| Helm | 1 tiller (helm wheel in option) |
| Rudder | 1 spade rudder |
| Cockpit | Closed aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Philippe Harlé |
Rig & Sails
| Mast | 42.8 |
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire |
| Number of spreaders | 2 |
| Spreaders angle | 0 ° |
| Upwind sail area | 54.53 sq.m |
| Downwind sail area | 92.35 sq.m |
Engine
| Engine A | |
| Power | 28 HP |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.04 |
| Upwind SA to Displacement | 20.59 |
| Downwind SA to Displacement | 34.87 |
| Hull Displacement Speed | 0.04 |
| Displacement to Length (D/L) | 6.99 |
| Ballast to Displacement (B/D) | 0.33 |
| Capsize Screening Formula (CSF) | 2.08 |
