Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
9.57 m
Specs
Main
Name | Value |
---|---|
Maker | Kirie |
Model | Elite 326-Deep Draft |
First built hull | 1987 |
Version | Deep Draft |
Boat type | Sail |
Category | Cruiser Boats |
Hull type | Monohull |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Top speed | 11.23 kmh |
Mast height | 13.05 m |
Length overall | 9.57 m |
Length at waterline | 8.29 m |
Beam overall | 3.38 m |
Headroom | 1.56 m |
Draft maximum | 1.58 m |
Displacement | 3,400.13 kg |
Ballast weight | 1,159.83 kg |
Ballast type | Cast Iron |
Helm | 1 tiller (helm wheel in option) |
Rudder | 1 spade rudder |
Cockpit | Closed aft cockpit |
Designer
Name | Value |
---|---|
No data |
Rig & Sails
Name | Value |
---|---|
Mast | 42.8 |
Spars | Mast and boom in Aluminum |
Standing rigging | 1x19 strand wire |
Number of spreaders | 2 |
Spreaders angle | 0 ° |
Upwind sail area | 54.53 sq.m |
Downwind sail area | 92.35 sq.m |
Mainsail A | 213.00 |
Spinnaker A | 782.00 |
Engine
Name | Value |
---|---|
Engine A | |
Power | 28 HP |
Type | Inboard engine |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.05 |
Upwind SA to Displacement | 24.53 |
Downwind SA to Displacement | 41.54 |
Hull Displacement Speed | 0.05 |
Displacement to Length (D/L) | 6.99 |
Ballast to Displacement (B/D) | 0.34 |
Capsize Screening Formula (CSF) | 2.27 |
