1987 Kirie Elite 326 - Shoal draft

1582

Report error

1987 Kirie Elite 326 - Shoal draft

No gallery images

1987 Kirie Elite 326 - Shoal draft
Preview

Boat Overview

Discover the Pro

Hide ads, help pay for servers & development and unlock Pro only features like, sharing, advanced dashboard, extra storage space & more!

Try Gold for Free

Specs

Main
NameValue
MakerKirie
ModelElite 326 - Shoal draft
First built hull1987
VersionShoal draft
Boat typeSail
CategoryCruiser Boats
Hull typeMonohull
Hull materialMonohull
General
NameValue
Top speed11.23 kmh
Mast height13.05 m
Length overall9.94 m
Length at waterline8.29 m
Beam overall3.38 m
Headroom1.83 m
Draft maximum1.34 m
Displacement4,419.8 kg
Ballast weight1,339.91 kg
Ballast typeCast iron
Helm1 tiller (helm wheel in option)
Rudder1 spade rudder
CockpitClosed aft cockpit
Designer
NameValue
Naval architect
Name/StudioPhilippe Harlé
Rig & Sails
NameValue
Mast42.8
SparsMast and boom in Aluminum
Standing rigging1x19 strand wire
Number of spreaders2
Spreaders angle0 °
Upwind sail area54.53 sq.m
Downwind sail area92.35 sq.m
Mainsail A213.00
Spinnaker A782.00
Spinnaker A68.00
Spinnaker A108.00
Engine
NameValue
Engine A
Power28 HP
TypeInboard engine ; Diesel
Engine B
Storage
NameValue
No data

Performance & Ratios

Detail
NameValue
Sail Area to Displacement (SA/D) 7.47
Upwind SA to Displacement20.59
Downwind SA to Displacement34.87
Hull Displacement Speed 6.99
Displacement to Length (D/L) 216.16
Ballast to Displacement (B/D) 30.32
Capsize Screening Formula (CSF) 2.08
