Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
11.31 m
Specs
Main
Name | Value |
---|---|
Maker | Kirie |
Model | Elite 37- Fin Keel |
First built hull | 1982 |
Version | Fin Keel |
Boat type | Sail |
Category | Cruiser Boats |
Hull type | Monohull |
Hull material | Fiberglass |
General
Name | Value |
---|---|
Top speed | 12.13 kmh |
Length overall | 11.31 m |
Length at waterline | 9.69 m |
Beam overall | 3.69 m |
Headroom | 1.86 m |
Draft maximum | 1.89 m |
Displacement | 5,800.08 kg |
Ballast weight | 2,399.96 kg |
Ballast type | Cast Iron |
Helm | 1 tiller (helm wheel in option) |
Rudder | 1 spade rudder |
Cockpit | Closed aft cockpit |
Designer
Name | Value |
---|---|
Naval architect | |
Name/Studio | Ron Holland |
Website | http://www.ronhollanddesign.com/ |
Rig & Sails
Name | Value |
---|---|
Spars | Mast and boom in Aluminum |
Standing rigging | 1x19 strand wire |
Number of spreaders | 2 |
Spreaders angle | 0 ° |
Upwind sail area | 76.92 sq.m |
Downwind sail area | 134.62 sq.m |
Mainsail A | 297.00 |
Spinnaker A | 1152.00 |
Spinnaker A | 89.00 |
Spinnaker A | 226.00 |
Engine
Name | Value |
---|---|
Engine A | |
Power | 28 HP |
Type | Inboard engine ; Diesel |
Engine B |
Storage
Name | Value |
---|---|
No data |
Performance & Ratios
Detail
Name | Value |
---|---|
Sail Area to Displacement (SA/D) | 0.05 |
Upwind SA to Displacement | 24.24 |
Downwind SA to Displacement | 42.41 |
Hull Displacement Speed | 0.05 |
Displacement to Length (D/L) | 7.56 |
Ballast to Displacement (B/D) | 0.41 |
Capsize Screening Formula (CSF) | 2.07 |
