Boat Overview
Type
Maker
Hull type
Hull Material
Fiberglass
Category
Boat length (LOA)
13.84 m
Specs
Main
| Maker | Kirie |
| Model | Elite 446 - Shoal draft |
| First built hull | 1988 |
| Version | Shoal draft |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Fiberglass |
General
| Top speed | 12.83 kmh |
| Length overall | 13.84 m |
| Length at waterline | 10.79 m |
| Beam overall | 4.48 m |
| Beam hull | 2.04 m |
| Draft maximum | 1.58 m |
| Displacement | 9,599.82 kg |
| Ballast weight | 2,699.78 kg |
| Ballast type | Cast iron |
| Helm | 1 wheel |
| Rudder | 1 spade rudder |
| Cockpit | Closed aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Philippe Harlé |
Rig & Sails
| Spars | Mast and boom in Aluminum |
| Number of spreaders | 2 |
| Spreaders angle | 0 ° |
| Upwind sail area | 94.58 sq.m |
| Downwind sail area | 160.63 sq.m |
Engine
| Engine A | |
| Power | 55 HP |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.04 |
| Upwind SA to Displacement | 21.3 |
| Downwind SA to Displacement | 36.17 |
| Hull Displacement Speed | 0.04 |
| Displacement to Length (D/L) | 7.97 |
| Ballast to Displacement (B/D) | 0.28 |
| Capsize Screening Formula (CSF) | 2.13 |
