Boat Overview
Type
Maker
Hull type
Hull Material
Composite_Material
Category
Boat length (LOA)
11.13 m
Specs
Main
| Maker | Kirie |
| Model | Feeling 1090 - Shoal draft |
| First built hull | 1986 |
| Version | Shoal draft |
| Boat type | Sail |
| Category | Cruiser Boats |
| Hull type | Monohull |
| Hull material | Composite_Material |
General
| Top speed | 11.59 kmh |
| Mast height | 15.18 m |
| Length overall | 11.13 m |
| Length at waterline | 8.57 m |
| Beam overall | 3.38 m |
| Beam center-line | 1.86 m |
| Draft maximum | 1.43 m |
| Displacement | 4,900.15 kg |
| Ballast weight | 1,999.89 kg |
| Ballast type | Cast iron |
| Helm | 1 wheel |
| Rudder | 1 spade rudder |
| Cockpit | Closed aft cockpit |
Designer
| Naval architect | |
| Name/Studio | Philippe Harlé ; Alain Mortain |
| Website | http://www.mortain-mavrikios.com/ |
Rig & Sails
| Mast | 49.8 |
| Spars | Mast and boom in Aluminum |
| Standing rigging | 1x19 strand wire |
| Number of spreaders | 2 |
| Spreaders angle | 0 ° |
| Upwind sail area | 70.98 sq.m |
| Downwind sail area | 120.96 sq.m |
Engine
| Engine A | |
| Power | 28 HP |
| Type | inboard |
| Engine B |
Storage
Performance & Ratios
Detail
| Sail Area to Displacement (SA/D) | 0.05 |
| Upwind SA to Displacement | 25.02 |
| Downwind SA to Displacement | 42.64 |
| Hull Displacement Speed | 0.05 |
| Displacement to Length (D/L) | 7.1 |
| Ballast to Displacement (B/D) | 0.41 |
| Capsize Screening Formula (CSF) | 2.01 |
| Kelsall Stability Index (KSI) | 553,672.83 |
